| Frame |
SuperSix EVO Carbon, Gen 5, integrated cable routing, 12x142 thru-axle, BSA 68mm threaded BB, flat mount disc, integrated seat binder, UDH |
| Fork |
SuperSix EVO Carbon, Gen 5, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/4" Delta steerer, 55mm offset (44-54cm), 45mm offset (56-61cm) |
| Rear Shock |
Null |
| Rims |
DT Swiss ERC LOG 45, carbon, 22mm inner width, 45mm depth, 24h, tubeless ready |
| Hubs |
(F) DT Swiss 370, 12x100mm centerlock / (R) DT Swiss 370 LN Ratchet System, 12x142mm centerlock |
| Spokes |
DT Swiss Competition |
| Tires |
Schwalbe One TLR, 700x28c, tubeless ready |
| Pedals |
Not included |
| Crank |
Shimano Ultegra R8100, 52/36: 165mm (44-50cm), 170mm (52-56cm), 172.5 (58-61cm) |
| Bottom Bracket |
Shimano BB-RS500, BSA 68 |
| Chain |
Shimano Ultegra, 12-speed |
| Rear Cogs |
Shimano Ultegra R8100, 11-30, 12-speed |
| Front Derailleur |
Shimano Ultegra Di2 R8150 |
| Rear Derailleur |
Shimano Ultegra Di2 R8150, 12-speed |
| Shifters |
Shimano Ultegra Di2 R8170, wireless, 2x12-speed |
| Handlebar |
Vision Trimax Carbon Aero: 380mm (44-56), 400mm (58-61) |
| Grips |
Cannondale Bar Tape, 3.5mm |
| Stem |
Cannondale C1 Conceal, Alloy, 31.8, -6°: 80mm (44cm), 90mm (48-52cm), 100mm (54-56cm), 110mm (58-61cm) |
| Headset |
Integrated, 1-1/8" - 1-1/4" |
| Brakes |
Shimano Ultegra R8170 hydraulic disc, 160/140mm CL800 rotors |
| Brake Levers |
Shimano Ultegra Di2 R8170 hydraulic disc |
| Saddle |
Fizik Vento Antares R5, S-Alloy rails, 140mm |
| Seatpost |
Cannondale C1 Aero 40 Carbon V2, 365mm, 0mm offset (44-54cm), 15mm offset (56-61cm) |
| Speeds |
24 |
| Extras |
Tubeless valves, Shimano EC300 charging connector, Conceal Stem accessory mount |
| Sizes Available |
44, 48, 50, 52, 54, 56, 58, 61 |
| Connectivity |
Null |
| Color 1 Description |
Tungsten Blue |
| Color 2 Description |
Raw |
